FEATURES
§ It can be used for tension preshrinking effect of flexible cloths, knitting cloths and weft yarn, making them easy to cut.
§ It has the function of forward and backward rotating, equipped with famous brand frequency inverter. The automatic shutdown for no cloths is designed for convenience and easy to operate.
§ It has the movable universal wheels, easy to handle.
Specification
Model | TF-210 | |
| Power supply | 1P/220V | |
| Diameter of cloths | 500mm | |
| cloth weight | 80kgs | 100kgs |
| Width of cloths | 82" | 92" |
| Inspection speed | 0-80yards/min | |
| Cloth spreading width | 600mm | |
| Machine size LxWxH(mm) | 2450x800x1200mm | 2650x800x1200 |
| Packing size LxWxH(mm) | 2580x810x1357mm | 2770x810x1357 |
| N.W / G.W | 300/400kgs | 500/600kgs |
